Plan‑Semi‑Apochromatic Objective

This semi‑apochromatic objective is intended for applications requiring extended spectral coverage, delivering flat‑field performance up to 25 mm. Fabricated from special‑formula glass for maximum light transmittance. Well‑suited for fluorescence‑imaging tasks and satisfies the fluorescence‑observation needs of most laboratory and scientific‑research projects.

Overview

Plan‑Semi‑Apochromatic Objective

Application

Objective

NA

W.D.(mm)

Cover-glass Thickness

Correction Ring

Spring-loaded

Bright-field

Dark-field

DIC

Phase Contrast

Polarization

Fluorescence

Visible

UV

NIR

Bright-field

N-PLFN

4×

0.13

17

-

◎

△

◎

◎

10×

0.3

15.8

0.17

◎

○

△

◎

◎

20×

0.5

2.7

0.17

◎

○

△

◎

◎

40×

0.75

1.35

0.17

√

◎

○

△

◎

◎

100×

1.4

0.18

0.17

√

◎

△

◎

◎

N-iPLFN

4×

0.13

16.2

1.2

◎

△

◎

◎

10×

0.3

15.7

1.2

◎

△

◎

◎

20×

0.45

8

1.2

◎

△

◎

◎

40×W

0.6

3.6

1.2

◎

△

◎

◎

20×C

0.45

8.80-7.50

0-2.00

√

√

◎

△

◎

◎

40×C

0.6

4.40-3.00

0-2.00

√

√

◎

△

◎

◎

60×C

0.7

2.60-1.80

0.10-1.30

√

√

◎

△

◎

◎

Phase Contrast

N-PLFN PH

4×Ph

0.13

17

-

○

◎

△

△

10×Ph

0.3

15.8

0.17

○

○

◎

△

△

20×Ph

0.5

2.7

0.17

○

○

◎

△

△

40×Ph

0.75

1.35

0.17

√

○

○

◎

△

△

100×Ph

1.4

0.18

0.17

√

○

◎

△

△

N-iPLFN PH

4×Ph

0.13

16.2

1.2

○

◎

△

△

10×Ph

0.3

15.7

1.2

○

◎

△

△

20×Ph

0.45

8

1.2

○

◎

△

△

40×Ph

0.6

3.6

1.2

○

◎

△

△

20× C Ph

0.45

8.80-7.50

0-2.00

√

√

○

◎

△

△

40×C Ph

0.6

4.40-3.00

0-2.00

√

√

○

◎

△

△

60×C Ph

0.7

2.60-1.80

0.10-1.30

√

√

○

◎

△

△

Imaging Demonstration
